Name: Bridges

Display Field: BridgeName

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The National Bridge Inventory (NBI) data applies to bridges with a span length of greater than 20 feet. This data is obtained and updated through the Department's Bridge Safety and Evaluation Unit, in accordance with the National Bridge Inspection Standards (23 CFR 650.3) and the CTDOT Bridge Inspection Manual. Its primary purpose is to provide bridge condition and other pertinent data for the annual Bridge Inventory submission to the FHWA. Town and State owned structures greater than 6 feet and less than 20 feet, along a state roadway, are also stored as part of the dataset but are excluded from the NBI data submittal to FHWA. Town owned bridges, along a town (local) roadway, less than 20 feet in length have a 6-digit bridge number and all State owned bridges have a 5 digit number. 6-digit bridges receive inspections on an as-needed basis. The NBI and Element data along with the inspection report are collected with the Bentley AWARI application and made available to Bridge and Highway design personnel as needed. The polygons shown are a Geo-spatial reference to the NBI data collected for each structure.</SPAN></P></DIV></DIV></DIV>

Service Item Id: e95b2fbfb82a4d1d92c9614e5fea083c

Copyright Text: Bridge Management Group, AEC Applications, Asset Management

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 733207.5759490579
YMin: 559357.3294278979
XMax: 1260650.422636047
YMax: 944114.5559749007
Spatial Reference: 103016  (6434)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: ServiceOnBridgeDescription
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: 1 - Highway
  Label: Highway
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 2
• Value: 4 - Highway-Railroad
  Label: Highway
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 2
• Value: 5 - Highway-Pedestrian
  Label: Highway
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 2
• Value: 6 - Overpass Structure At An Interchange Or Second
  Label: Highway
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 2
• Value: 7 - Third Level (Interchange)
  Label: Highway
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 2
• Value: 8 - Fourth Level (Interchange)
  Label: Highway
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [0, 112, 255, 255]
  Outline:
  Style: esriSLSSolid
  Color: [78, 78, 78, 255]
  Width: 2
• Value: 2 - Railroad
  Label: Railroad
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [255, 0, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 2
• Value: 0 - Other
  Label: Ped-Bike-Other
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [85, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 2
• Value: 3 - Pedestrian-Bicycle
  Label: Ped-Bike-Other
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [85, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 2
• Value: 9 - Building Or Plaza
  Label: Ped-Bike-Other
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [85, 255, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 2
• Value:
  Label: No SMS Data
  Description: N/A
  Symbol:
  Style: esriSFSSolid
  Color: [156, 156, 156, 255]
  Outline:
  Style: esriSLSSolid
  Color: [52, 52, 52, 255]
  Width: 2
Transparency: 40
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [BridgeStructureNumber]
Use Coded Values: true
Symbol:
Color: [0, 92, 230, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: center
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 24000.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• BridgeStructureNumber ( type: esriFieldTypeString, alias: Bridge Structure Number, length: 10 )
• BridgeName ( type: esriFieldTypeString, alias: Bridge Name, length: 200 )
• AssetTypeName ( type: esriFieldTypeString, alias: Asset Type Name, length: 20 )
• FacilityCarried_NBI7 ( type: esriFieldTypeString, alias: Facility Carried (NBI 7), length: 100 )
• FeatureCrossed_NBI6A ( type: esriFieldTypeString, alias: Feature Crossed (NBI 6A), length: 100 )
• Town_NBI4 ( type: esriFieldTypeString, alias: Town (NBI 4), length: 20 )
• DeckConditionRating_NBI58 ( type: esriFieldTypeString, alias: Deck Condition Rating (NBI 58), length: 10 )
• DeckConditionRating_Descrn ( type: esriFieldTypeString, alias: Deck Condition Rating (NBI 58) Description, length: 50 )
• SuperSTRConditionRating_NBI59 ( type: esriFieldTypeString, alias: Superstructure Condition Rating (NBI 59), length: 10 )
• SuperSTRConditionRating_Descrn ( type: esriFieldTypeString, alias: Superstructure Condition Rating (NBI 59) Description, length: 50 )
• SubSTRConditionRating_NBI60 ( type: esriFieldTypeString, alias: Substructure Condition Rating (NBI 60), length: 10 )
• SubSTRConditionRating_Descrn ( type: esriFieldTypeString, alias: Substructure Condition Rating (NBI 60) Description, length: 50 )
• CulvertConditionRating_NBI62 ( type: esriFieldTypeString, alias: Culvert Condition Rating (NBI 62), length: 10 )
• CulvertConditionRating_Descrn ( type: esriFieldTypeString, alias: Culvert Condition Rating (NBI 62) Description, length: 50 )
• NationalHighwaySystem_NBI104 ( type: esriFieldTypeString, alias: National Highway System (NBI 104), length: 10 )
• NHS_Description ( type: esriFieldTypeString, alias: National Highway System (NBI 104), length: 10 )
• NBISBridgeLength_NBI112 ( type: esriFieldTypeString, alias: NBIS Bridge Length (NBI 112), length: 10 )
• FHWA_DeckArea_SQFT ( type: esriFieldTypeDouble, alias: FHWA Deck Area in SQFT )
• YearBuilt_NBI27 ( type: esriFieldTypeInteger, alias: Year Built (NBI 27) )
• YearReconstructed_NBI106 ( type: esriFieldTypeInteger, alias: Year Reconstructed (NBI 106) )
• ScourCriticalRating_NBI113 ( type: esriFieldTypeString, alias: Scour Critical Rating (NBI 113), length: 10 )
• ScourCriticalRating_Descrn ( type: esriFieldTypeString, alias: Scour Critical Rating (NBI 113) Description, length: 50 )
• RouteNumber_NBI5D ( type: esriFieldTypeString, alias: Route Number (NBI 5D), length: 10 )
• Milepoint_NBI11 ( type: esriFieldTypeDouble, alias: Milepoint (NBI 11) )
• AverageDailyTraffic_NBI29 ( type: esriFieldTypeInteger, alias: Average Daily Traffic (NBI 29) )
• YearofAvgDailyTraffic_NBI30 ( type: esriFieldTypeInteger, alias: Year of Averge Daily Traffic (NBI 30) )
• Owner_NBI22 ( type: esriFieldTypeInteger, alias: Owner (NBI 22) )
• OwnerValue_Description ( type: esriFieldTypeString, alias: Owner Value (NBI 22) Description, length: 50 )
• Maintenance_NBI21 ( type: esriFieldTypeInteger, alias: Maintenance (NBI 21) )
• MaintenanceValue_Description ( type: esriFieldTypeString, alias: Maintenance (NBI 21) Description, length: 50 )
• InspectionDate_NBI90 ( type: esriFieldTypeDate, alias: Inspection Date (NBI 90), length: 8 )
• InspectionFrquency_NBI91 ( type: esriFieldTypeInteger, alias: Inspection Frquency (NBI 91) )
• StructureLength_NBI49 ( type: esriFieldTypeDouble, alias: Structure Length (NBI 49) )
• MainSpan_NBI45 ( type: esriFieldTypeInteger, alias: Main Span (NBI 45) )
• MainSpanMaterialCode_NBI43A ( type: esriFieldTypeInteger, alias: Main Span Material Code (NBI 43A) )
• MainSpanMaterialDescription ( type: esriFieldTypeString, alias: Main Span Material Code (NBI 43A) Description, length: 50 )
• MainSpanDesignCode_NBI43B ( type: esriFieldTypeInteger, alias: Main Span Design Code (NBI 43B) )
• MainSpanDesignDescription ( type: esriFieldTypeString, alias: Main Span Design Code (NBI 43B) Description, length: 50 )
• ApproachSpans_NBI46 ( type: esriFieldTypeInteger, alias: Approach Spans (NBI 46) )
• ApproachSpanMaterial_NBI44A ( type: esriFieldTypeInteger, alias: Approach Span Material (NBI 44A) )
• ApproachSpanMatDescription ( type: esriFieldTypeString, alias: Approach Span Material (NBI 44A) Description, length: 50 )
• ApproachSpanCode_NBI44B ( type: esriFieldTypeInteger, alias: Approach Span Code (NBI 44B) )
• ApproachSpanDescription ( type: esriFieldTypeString, alias: Approach Span Code (NBI 44B) Description, length: 50 )
• ServiceOnBridgeCode_NBI42A ( type: esriFieldTypeInteger, alias: Service On Bridge Code (NBI 42A) )
• ServiceOnBridgeDescription ( type: esriFieldTypeString, alias: Service On Bridge Code (NBI 42A) Description, length: 50 )
• ServiceUnderBridgeCode_NBI42B ( type: esriFieldTypeInteger, alias: Service Under Bridge Code (NBI 42B) )
• ServiceUnderBridgeDescription ( type: esriFieldTypeString, alias: Service Under Bridge Code (NBI 42B) Description, length: 50 )
• PostedLdSingleUnit_6000034 ( type: esriFieldTypeString, alias: Posted Load Single Unit, length: 20 )
• PostedLoadSemiTrlr_6000036 ( type: esriFieldTypeString, alias: Posted Load SemiTrailer, length: 20 )
• PostedLoad4Axle_6000038 ( type: esriFieldTypeString, alias: Posted Load 4Axle, length: 20 )
• PostedLoad3S2_6000040 ( type: esriFieldTypeString, alias: Posted Load 3S2, length: 20 )
• PostedLoadAll_6000042 ( type: esriFieldTypeString, alias: Posted Load All, length: 20 )
• PostedVertUnderClrncFt ( type: esriFieldTypeInteger, alias: Posted Vertical Under Clearance Ft )
• PostedVertUnderClrncIN ( type: esriFieldTypeInteger, alias: Posted Vertical Under Clearance In )
• PostedVertClrncFt_6000029 ( type: esriFieldTypeInteger, alias: Posted Vertical Clearance Ft )
• PostedVertClrncIN_6000030 ( type: esriFieldTypeInteger, alias: Posted Vertical Clearance In )
• PostedSpeedLimit_6000033 ( type: esriFieldTypeInteger, alias: Posted Speed Limit )
• DeckWidthOut2OutFT_NBI52 ( type: esriFieldTypeDouble, alias: Deck Width Out to Out Ft (NBI 52) )
• ApproachRoadwayWidthFT_NBI32 ( type: esriFieldTypeDouble, alias: Approach Roadway Width Ft (NBI 32) )
• FractureCritiInspDate_NBI93A ( type: esriFieldTypeDate, alias: Fracture Critical Inspection Date (NBI 93A), length: 8 )
• FractureCritFreq_NBI92A ( type: esriFieldTypeInteger, alias: Fracture Critical Frequency (NBI 92A) )
• SpecialInspectionDate_NBI93C ( type: esriFieldTypeDate, alias: Special Inspection Date (NBI 93C), length: 8 )
• SpecialInspFrequency_NBI92C ( type: esriFieldTypeInteger, alias: Special Inspection Frequency (NBI 92C) )
• UnderwaterInspDate_NBI93B ( type: esriFieldTypeDate, alias: Underwater Inspection Date (NBI 93B), length: 8 )
• UnderwaterInspFreq_NBI92B ( type: esriFieldTypeInteger, alias: Underwater Inspection Frequency (NBI 92B) )
• ApproachRdwyAlignment_NBI72 ( type: esriFieldTypeString, alias: Approach Roadway Alignment (NBI 72), length: 10 )
• ApproachRdwyAlignment_Descrn ( type: esriFieldTypeString, alias: Approach Roadway Alignment (NBI 72) Description, length: 50 )
• ChannelProtectionRating_NBI111 ( type: esriFieldTypeString, alias: Channel Protection Rating (NBI 111), length: 10 )
• ChannelProtectionRating_Descrn ( type: esriFieldTypeString, alias: Channel Protection Rating (NBI 111) Description, length: 50 )
• StructureEvaluation_NBI67 ( type: esriFieldTypeString, alias: Structure Evaluation (NBI 67), length: 10 )
• StructureEvaluation_Descrn ( type: esriFieldTypeString, alias: Structure Evaluation (NBI 67) Description, length: 50 )
• UnderClearanceRating_NBI69 ( type: esriFieldTypeString, alias: Under Clearance Rating (NBI 69), length: 10 )
• UnderClearanceRating_Descrn ( type: esriFieldTypeString, alias: Under Clearance Rating (NBI 69) Description, length: 50 )
• WaterwayAdequacy_NBI71 ( type: esriFieldTypeString, alias: Waterway Adequacy (NBI 71), length: 10 )
• WaterwayAdequacy_Descrn ( type: esriFieldTypeString, alias: Waterway Adequacy (NBI 71) Description, length: 50 )
• VertClearanceRestriction_NBI53 ( type: esriFieldTypeString, alias: Vertical Clearance Restriction (NBI 53), length: 50 )
• MinVertClearanceUnderFt_NBI54B ( type: esriFieldTypeInteger, alias: Minimum Vertical Clearance Under Ft (NBI 54B) )
• MinVertClearanceUnderIN_NBI54B ( type: esriFieldTypeInteger, alias: Minimum Vertical Clearance Under In (NBI 54B) )
• DeckGeometryRating_NBI68 ( type: esriFieldTypeString, alias: Deck Geometry Rating (NBI 68), length: 10 )
• DeckGeometryRating_Descrn ( type: esriFieldTypeString, alias: Deck Geometry Rating (NBI 68) Description, length: 50 )
• InspecTechBridgeDataID ( type: esriFieldTypeInteger, alias: InspecTech Bridge Data ID )
• AssetTypeID ( type: esriFieldTypeInteger, alias: Asset Type ID )
• BridgeClass ( type: esriFieldTypeString, alias: Bridge Class, length: 10 )
• BridgeClass_Description ( type: esriFieldTypeString, alias: Bridge Class Description, length: 50 )
• DocumentLink ( type: esriFieldTypeString, alias: Document Link, length: 200 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Relationships:

• Active Projects (0) -- Related To: Active Projects (2)
• Completed Projects (1) -- Related To: Completed Projects (1)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
