Name: Signal Control Areas

Display Field: AreaID

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: The traffic signal control area polygons were developed by the CTDOT and updated by UConn and VHB. The feature class was developed by digitizing the area that represents the geographic extent of the signalized intersections. Attributes were migrated from the previous system and only the intersection number has been maintainted. Long term plans are to remove some of the fields and migrate them to correct geographic asset in the signals data model. This will preserve the asset lifecycle.

Service Item Id: aa8e1323555948f69f1d7ec38d8ee8b5

Copyright Text: Connecticut Department of Transportation, UConn, VHB

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 750169.994123891
YMin: 563188.3841017336
XMax: 1253812.6384113878
YMax: 935700.6390757263
Spatial Reference: 103016  (6434)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [179, 179, 252, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID_1 ( type: esriFieldTypeOID, alias: OBJECTID_1 )
• AreaID ( type: esriFieldTypeString, alias: AreaID, length: 80 )
• latitude ( type: esriFieldTypeDouble, alias: latitude )
• longitude ( type: esriFieldTypeDouble, alias: longitude )
• ProjectWis ( type: esriFieldTypeInteger, alias: Project Wise )
• ID_ExtMnt ( type: esriFieldTypeString, alias: Extraordinary Maintenance (Yes, No), length: 254 , Coded Values: [Yes: Yes] , [No: No] )
• LOC_CrsST ( type: esriFieldTypeString, alias: Location Cross Street, length: 254 )
• LOC_TOWN ( type: esriFieldTypeString, alias: Location Town, length: 254 )
• LOC_AltNm ( type: esriFieldTypeString, alias: Location Alt Route Number, length: 254 )
• ID_SigTyp ( type: esriFieldTypeString, alias: Signal Type, length: 254 , Coded Values: [Traffic Control Signal, Fully-Actuated: Traffic Control Signal, Fully-Actuated] , [Traffic Control Signal, Fully-Actuated with Wrong-Way Detection System: Traffic Control Signal, Fully-Actuated with Wrong-Way Detection System] , [Traffic Control Signal, Semi-Actuated: Traffic Control Signal, Semi-Actuated] , ...10 more... )
• ID_Mnt ( type: esriFieldTypeString, alias: Maintenance Level, length: 254 , Coded Values: [Level 1 (24 Hr): Level 1 (24 Hr)] , [Level 2 (Commuter): Level 2 (Commuter)] , [Level 3 (Shopping Ctr): Level 3 (Shopping Ctr)] , ...5 more... )
• MST_FndQty ( type: esriFieldTypeInteger, alias: Mast Arm Foundation Quantity (Single Arm) )
• MST_FndTwn ( type: esriFieldTypeInteger, alias: Mast Arm Foundation Quantity (Twin Arm) )
• MST_SpnIns ( type: esriFieldTypeInteger, alias: Mast Arm/Span Pole Original Install Year )
• ID_Own ( type: esriFieldTypeString, alias: Signal Owner (State, Town, Other), length: 254 , Coded Values: [State: State] , [Town: Town] , [Other: Other] )
• PED_WkTyp ( type: esriFieldTypeString, alias: Pedestrian Type (None, Exclusive, Side Street, Concurrent), length: 254 , Coded Values: [Side Street Green: Side Street Green] , [Concurrent: Concurrent] , [Concurrent W/ LPI: Concurrent W/ LPI] , ...2 more... )
• LOC_RteNO ( type: esriFieldTypeString, alias: Location Route Number, length: 254 )
• SPN_SpnQty ( type: esriFieldTypeInteger, alias: Span Pole Foundation Quantity )
• LOC_IntNO ( type: esriFieldTypeString, alias: Location Intersection Number, length: 254 )
• ID_UtlPl ( type: esriFieldTypeInteger, alias: Utility Pole Quantity )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• ControllerType ( type: esriFieldTypeString, alias: Controller Manufacturer/Model, length: 75 , Coded Values: [Auto/Eagle EPAC M10 M30: Auto/Eagle EPAC M10 M30] , [Automatic 318/324: Automatic 318/324] , [Crouse Hinds DM Series: Crouse Hinds DM Series] , ...16 more... )
• ConflictMonitorType ( type: esriFieldTypeString, alias: Conflict Monitor Type, length: 75 , Coded Values: [EDI MMU2-16LE(ip): EDI MMU2-16LE(ip)] , [EDI NSM-12: EDI NSM-12] , [EDI SSM-12LE: EDI SSM-12LE] , ...7 more... )
• Status ( type: esriFieldTypeString, alias: Status, length: 255 , Coded Values: [1: Planned] , [2: Commissioned] , [3: Decommissioned] , ...6 more... )
• ATSPMAvailable ( type: esriFieldTypeString, alias: ATSPM Available, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• SPaTAvailable ( type: esriFieldTypeString, alias: SPat Available, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• DetectionWorking ( type: esriFieldTypeString, alias: Detection Working, length: 5 , Coded Values: [1: Yes] , [0: No] )
• DetectionInspection ( type: esriFieldTypeDate, alias: Detection Inspection Date, length: 8 )
• ID_PrgFL ( type: esriFieldTypeString, alias: Programmed Flashing Operation (Yes, No), length: 50 , Coded Values: [1: Yes] , [0: No] )
• CAD_Rev ( type: esriFieldTypeString, alias: CAD Revision Number, length: 10 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
