Parent Layer: Roadway

Name: Routing Segments

Display Field: TOWN_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: GIS Layer representation of the State Route Centerline Road Network for the Connecticut Department of Transportation

Service Item Id: a0b78dbf467d43eab89bda7e39d20ece

Copyright Text: Roadway Information System, AWLRS, TIG

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 5000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 733141.0058722198
YMin: 559994.4472481459
XMax: 1262554.547764808
YMax: 944207.4051986486
Spatial Reference: 103016  (6434)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSDash
Color: [0, 0, 0, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• ROUTE_ID ( type: esriFieldTypeString, alias: RouteID, length: 30 )
• BEGIN_POINT ( type: esriFieldTypeDouble, alias: BeginMilePoint )
• END_POINT ( type: esriFieldTypeDouble, alias: EndMilePoint )
• ROUTE_DIR ( type: esriFieldTypeString, alias: RouteDirection, length: 1 , Coded Values: [L: Log] , [R: Reverse] )
• ROUTE_PREFIX ( type: esriFieldTypeString, alias: RoutePrefix, length: 4 , Coded Values: [I: Interstate Route] , [US: US Route] , [CT: Connecticut Route] , ...5 more... )
• ROUTE_NUMBER ( type: esriFieldTypeString, alias: RouteNumber, length: 4 )
• ROUTE_SUFFIX ( type: esriFieldTypeString, alias: RouteSuffix, length: 4 )
• RAMP_NUMBER ( type: esriFieldTypeString, alias: RampNumber, length: 4 )
• RAMP_SUFFIX ( type: esriFieldTypeString, alias: RampSuffix, length: 4 )
• ROAD_TYPE ( type: esriFieldTypeString, alias: RoadType, length: 4 , Coded Values: [M: Mainline] , [ER: Entrance Ramp] , [XR: Exit Ramp] , ...5 more... )
• TOWN_NUMBER ( type: esriFieldTypeString, alias: DOTTownNumber, length: 4 )
• TOWN_NAME ( type: esriFieldTypeString, alias: TownName, length: 50 )
• PRI_SEC_STATUS ( type: esriFieldTypeString, alias: OverlapStatus, length: 4 , Coded Values: [PRI: Primary] , [SEC: Secondary] )
• YEAR ( type: esriFieldTypeString, alias: SnapshotYear, length: 4 )
• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
